Infrared Ultrafast Fiber Lasers
Infrared Ultrafast Fiber Lasers
产品特点
-
Wavelength：1055±15nm
Pulse Width：50fs
Average Power：>500mW
High Stability，Short pulse
Pulse Width：50fs
Average Power：>500mW
High Stability，Short pulse
产品概述
Theotech's independently developed and manufactured ultrafast femtosecond laser features a central wavelength of 1055±15 nm, with a minimum pulse width of 50 fs, single-pulse energy exceeding 50 nJ, and average power over 500 mW. Utilizing non-SESAM mode-locking technology, the laser ensures stable and reliable operation with strong resistance to environmental interference. It is widely applied in bioimaging, ultrafast spectroscopy, and micro/nano-processing fields.
规格参数
| Part No. 产品型号 | TFS-50 |
| Central Wavelength (nm) | 1055±15 |
| 中心波长 | |
| 10 dB Spectral Width (nm) | >80, typ. 95 |
| 10 dB 光谱线宽 | |
| Repetition Rate (MHz) | 22 ± 0.5 |
| 重复频率 | |
| Pulse Width (fs) | <80, typ. 50 |
| 脉冲宽度 | |
| Chirp | Customizable design 可根据用户要求设计 |
| 啁啾 | |
| Maximum Chirped Pulse Duration (ps) | >5 |
| 最大啁啾脉冲宽度 | |
| Average Power (mW) | >500 |
| 平均功率 | |
| Pulse Energy (nJ) | >50 |
| 单脉冲能量 | |
| Polarization | Linear 100：1 |
| 偏振特性 | |
| Beam Quality （M²） | <1.2 |
| 光束质量 | |
| Connector | Customizable design 可根据用户要求设计 |
| 接头 | |
| Operating Temperature (℃) | 15~35 |
| 工作温度 | |
| Storage Temperature (℃) | 0~60 |
| 存储温度 | |
| Supply Power | 100-240 VAC, 50/60Hz |
| 电源输入 | |
| Power Dimensions(WxHxL,mm) | 180x120x400 |
| 控制电源尺寸 | |
| Laser Head Dimensions(WxHxL,mm) | 450x130x580 |
| 激光头尺寸 |
